When comparing AV receivers and amplifiers, you'll often see two key power specifications listed: Watts RMS and Dynamic Power. Understanding the difference between these ratings is essential when evaluating different models, as manufacturers can present power figures in ways that may not always be directly comparable.
Let’s break down what these terms mean and how to use them effectively when choosing an amplifier or AV receiver.
What is Watts RMS?
RMS (Root Mean Square) power is the most reliable measurement of an amplifier’s continuous power output. It represents the amount of power an amplifier can deliver consistently over an extended period without distortion or overheating.
- Real-World Performance - RMS ratings are considered the most accurate representation of how an amplifier will perform in typical listening conditions.
- Measured with Load Resistance - RMS power is measured by driving a continuous sine wave signal into a specified speaker impedance (usually 8Ω or 4Ω).
- Consistent Between Models - Since RMS power follows a standardised testing method, it’s the best spec for directly comparing amplifiers.
For example, an AV receiver rated at 100W RMS per channel (8Ω, 20Hz-20kHz, 0.08% THD, 2 channels driven) means that the amp can sustain 100 watts of clean power per channel when driving two speakers simultaneously with very low distortion within the full audio spectrum.
It's very important to compare power ratings with at least 2 channels driven at the same time, as this additional load will put pressure on the power supply, providing a more accurate real world example.
What is Dynamic Power?
Dynamic power, sometimes referred to as Peak Power or Instantaneous Power, represents the short-term power an amplifier can produce during audio peaks. This is important because music and movies contain transient bursts of sound, such as explosions or orchestral crescendos, that require higher power output for brief moments.
- Short-Term Bursts - Dynamic power is measured using short-duration test signals rather than continuous sine waves.
- Influenced by Power Supply Design - Amplifiers with larger capacitors and robust power supplies will have higher dynamic power ratings.
- Not Standardised - Different manufacturers may use different methods to measure and report dynamic power, making it harder to compare between brands.
For instance, an amplifier rated at 100W RMS per channel may have a dynamic power rating of 150W or more per channel at 8Ω, allowing it to handle sudden increases in demand without distortion.
How to Read and Compare Power Ratings
When shopping for an AV receiver or power amplifier, here’s how to interpret power ratings effectively:
1. Prioritise RMS Power Over Dynamic Power
RMS power is the most reliable measurement for real-world performance. If an amplifier has a high dynamic power rating but a low RMS rating, it may struggle to deliver sustained power over time.
2. Check the Impedance and Number of Channels Driven
Some manufacturers list power ratings at 6Ω instead of 8Ω, which can artificially inflate the wattage figure. Also, always check if the power rating is given for two channels driven or all channels driven—some AV receivers advertise high wattage but only when running two channels.
3. Look at the Total Harmonic Distortion (THD) Level
Power ratings should ideally be given with a THD of 0.1% or lower for clean, undistorted power output. Some manufacturers list power at 1% or even 10% THD, which means the amp is pushing into distortion to achieve that number.
4. Compare Power Supplies and Capacitors
AV receivers with larger power supplies and capacitors can handle transients better, providing higher dynamic power without clipping. Heavier amplifiers often indicate better-built power supplies.
5. Be Wary of Marketing Gimmicks
If a manufacturer lists high peak power (e.g., 1000W PMPO) but low RMS power (e.g., 50W RMS per channel), it's a sign that the amp is not as powerful as it appears on paper. Always focus on RMS ratings.
Understanding the difference between Watts RMS and Dynamic Power is crucial when comparing amplifiers and AV receivers. RMS power is the most important metric as it reflects continuous, real-world performance, while Dynamic Power gives insight into an amp’s ability to handle short-term peaks. By carefully reading power specs, checking for misleading marketing claims, and comparing key factors like impedance, THD, and power supply design, you can make a more informed decision and choose an amplifier that delivers the performance you need.
