AudioControl Concert XR-6S 9.1.6 Immersive AV Receiver 7ch Class AB

AudioControl  /  AV Receivers

ACP-XR-6S

$9,999.00
/
Buy now, pay later with: Zip Interest Free Afterpay Interest Free Humm Interest Free
  • Free Delivery Australia Wide
  • Local Australian Warranty
  • 1800 100 998 For Assistance

We take pride in our customer service and shipping times. Most products will ship within 1-2 business days. If there are any potential delays with products in your order, we will contact you.

All orders now come with free shipping Australia Wide.

We use a variety of shipping methods depending on the types of items purchased and their delivery location. This helps to ensure your items arrive safely and in a timely manner. If you are on a tight deadline or would like to know an estimated delivery date for your order, contact our friendly staff and they will be happy to assist.

Orders will usually take between 1-6 days for delivery, depending on your location and shipping method.

If your order has not been delivered within 7 days of shipping we recommend you reach out to us directly to investigate with Australia Post / Courier.

If for any reason you haven't followed up with us within 30 days of shipping, we'll be unable to guarantee your delivery of your item unless it has been returned to sender.

Key Features

  • ES9026PRO SABRE audiophile DACs (124 dB of dynamic range)
  • 7 channels of high power Class AB amplification
  • All inputs support 8K/60 p and 4K/120 p
  • 9.1.6 Processing for Dolby Atmos, DTS:X, IMAX Enhanced, and Auro-3D
  • Includes Dirac Live® & Dirac Live® Bass Control

Take your home theatre experience to the next level with the AudioControl Concert XR-6S, a high-performance 8K UHD 9.1.6 AV receiver designed to deliver exceptional sound and video quality. Engineered to support the latest Dolby Atmos, Auro-3D, DTS:X, and IMAX Enhanced formats, this receiver ensures a truly immersive cinematic experience.

Features:

  • Superior audio processing: Equipped with Dirac Live® room correction, the XR-6S analyses and optimises your space for precise, distortion-free audio.
  • High-performance DACs: Featuring ESS SABRE PRO digital-to-analogue converters, this receiver delivers crystal-clear sound with deep, authoritative bass.
  • Powerful amplification: Seven channels of Class AB amplification provide 100 watts per channel, ensuring dynamic and lifelike performance.
  • Comprehensive connectivity: Includes seven HDMI inputs and three HDMI outputs, supporting Zone 2 and eARC, allowing seamless integration with your home entertainment system.
  • Future-proof video support: Handles 8K/60Hz and 4K/120Hz resolutions, ensuring compatibility with the latest video standards.
  • Versatile streaming options: Stream effortlessly with Google Chromecast®, Apple® AirPlay 2, Roon Ready, Bluetooth with aptX HD®, and Wi-Fi.
  • Customisable outputs: Four user-assignable preamp output channels provide flexibility for advanced speaker configurations.
  • HDR compatibility: Fully supports Dolby Vision, HDR10+, HDR10, and HLG for stunning visual clarity and contrast.

Designed for audiophiles and home cinema enthusiasts alike, the AudioControl Concert XR-6S combines cutting-edge technology with refined aesthetics, making it the perfect centrepiece for any premium home theatre setup.

Experience the ultimate in sound and vision with the AudioControl Concert XR-6S.

Specifications

INPUTS
Audio Inputs: 7 HDMI, 6 RCA Phono, 4 Coax SPDIF, 2 TOSLINK
Nominal sensitivity: 1 V, 2 V, 4 V (user selectable)
Input Impedance: 47 kΩ
Signal to Noise (A-wtd ref 100W) normal/stereo direct: 100 dB/110 dB
Frequency Response: 20 Hz to 20 kHz ± 0.2 dB
Video Inputs: 7 HDMI (HDMI 2.1 / HDCP 2.3)		 GENERAL
Power consumption (standby): <0.5W
Power consumption (idle, typical): 90W (340 BTU/hour)
Power consumption (maximum): 1500W (5200 BTU/hour)
OUTPUTS
Amplifier Channels: 7
Continuous power output, per channel, 8Ω / 4Ω:  100W
Minimum Speaker Load: 4Ω
Preamp Audio Outputs: 16 channels (unbalanced RCA), 2 channels Zone 2 (unbalanced RCA), 1 TOSLINK
Nominal output level: 1 Vrms (max. 5 Vrms)
Output impedance: 560 Ω
THD+N (20 Hz to 20 kHz): -100dB
Main Video Outputs: Dual (2) HDMI (eARC support)
Second Zone Output: 1 HDMI
Headphone Output: 1 1/4″		 WEIGHT & DIMENSIONS
Dimensions (including terminals and feet): 17” W x 17.5” D x 7.3” H (4 U)
Weight: 40.3 lbs. (18.3 kg)
CONTROL
IP Ethernet
Wi-Fi
RS232 Serial Control
12 Volt Trigger Outputs: 2
IR Receiver Inputs: 2		 IN THE BOX
Concert XR-6S, HTR-3 remote with 2 x AAA batteries, DAB/FM antenna, 3 x WiFi/Bluetooth antennas, calibration microphone, USB cable, power cord, rack mounting brackets, user manual, warranty
